Overrun brake AL-KO 251S PLUS, 1500-2700 kg (for Gromex 2700 kg)
Code: 60306Related products
Product detailed description
Modernized version of the overrun brake AL-KO 251S PLUS. The brake is supplied including a safety cable and a towing coupling AL-KO AK 270.
- Adjustment of the double arm lever for different types of wheel units.
As standard, the brake is supplied set for wheel units AL-KO 2051. The brake is also compatible with wheel brake units AL-KO 1636G, 1637, 2361, 3061 and 3081. Three holes are drilled in the upper part of the double lever with the gear ratio marking. By moving the pin of the lower part of the lever into the appropriate hole, the brake can be adjusted for each wheel unit, see figure and table below.
- On request, we can supply the brake set to any of the above wheel units.
Technical parameters:
| top mounting | Yes |
| bottom mounting | Yes |
| Manufacturer | AL-KO |
| for total trailer weight min. (kg) | 1500 |
| for total trailer weight max. (kg) | 2700 |
| maximum permissible vertical load (kg) | 120 |
| suitable for drawbar | V-drawbar |
| service number AL-KO (ETI) | 807080 |
| connecting device | AK 270 |
Additional parameters
| Category: | Overrun brakes for V-shaped drawbar trailers |
|---|---|
| for total trailer weight min. (kg): | 1500 |
| for total trailer weight max. (kg): | 2700 |
| maximální povolené svislé zatížení (kg): | 120 |
| drawbar mountable: | V-drawbar |
| connecting device: | AL-KO AK 270 |
| service number AL-KO (ETI): | 807080 |
| bottom mounting: | Yes |
| top mounting: | Yes |
